Product Description
Description:
BY-07 marking model is a patent model which is mostly for ￠100-￠700mm big and heavy metal workpiece circumference marking. For example: stainless stell flange ,carbon steel flange, alloy steel flange ,forged ring, pipe , pipe fitting ..... The design of block-out controlling cabinet benefits for damp-proof ,dust-proof, shake-proof, meanwhile , the dust-proof marking head with aluminum alloy which could protect dust or metal mote sparking into marking head and re-long using life . it could be used in the wicked working condition.
Marking machine high performance
◆Marking contents: all kinds of logo (characters , Alphanumeric , date, numbers , serial No, VIN codes, graph ,ect) on any metal.
◆support both plane marking (curve or any angle) and circumference marking .
◆support flat or regular convex surface marking
◆Support “line” and “dot ” marking
Marking software function :
◆Support WINDOWS98/XP
◆Support multi-kinds fond
◆Support linear ,angular , radial , indination, inverted ,mirrored marking .
◆All the logo size could changeable as will
◆Marking speed is changeable as will
◆ protect VIN code exactness automatically
◆Support . MVG format graph from CAD ,CORLEDRAW
◆ALL marking contect could be saved as .xls format file.
◆ Simple graph could draw directly by our marking software
◆ support series No and mass data marking one by one automatically
◆Marking contents could be saved automatically and not be destroyed due to the electric-break
◆Connect with ARGOX PPLA , ARGOX PPLB and barcode timing output
Main tech-specification :
|
Marking speed
|
3-5 letter /S
|
|
Hitting frequency
|
300HZ
|
|
Marking depth
|
0.1-1mm(according to the workpiece material )
|
|
Marking accuracy
|
0.02mm
|
|
Marking scope
|
110*80mm (customrization any marking area )/360 degreen
|
|
Pinhead hardness
|
HRA92
|
|
Workpiece hardness allowed
|
≤HRC62
|
|
Inputting air pressure
|
0.3-0.6MPA
|
|
Power consumption
|
≤550W
|
|
Voltage
|
AC220V±10%，50Hz
|
|
Working Temperature
|
0℃-40℃
|
|
Relative humidity
|
≤90%
|
Application
stainless stell flange ,carbon steel flange, alloy steel flange ,forged ring, pipe , pipe fitting
Product Image
